30mm On-Metal PVC Disc NTAG213

A 30mm PVC disc tag with ferrite backing suitable for use on both metal and non-metal surfaces. NTAG213 NFC chip. This tag also has strong 3M9080 backing adhesive for easy attachment. Available from stock as a plain gloss white unit or as a special order with full colour print and optional unique elements (QR code / ID print).

This is a popular and economical tag for on-metal object or location tagging in high use environments where the additional protection over a standard label can be important. The NFC chip and antenna are fully enclosed within the PVC and the high tack 3M9080 adhesive provides a strong bond to even LSE plastics.

This tag can be used outside in sheltered locations but we don't recommend it's use in exposed areas or areas subject to regular water as the ferrite material is not completely enclosed inside the tag. For a more durable water and weather resistant option, consider our Industrial or Warehouse tags.

On-Metal Tags Explained

Normal NFC tags do not work when placed directly onto metal surfaces. Therefore, when using NFC tags on metal you either need a gap of at least 0.5 cm between the tag and the metal or you can use a special tag which has a barrier material, called ferrite, between the NFC tag and the adhesive. This barrier material gives you the same effect as if you had created the gap between the metal surface and the tag.

These NFC tags designed so they can be placed on metal surfaces are called 'on-metal' tags (or sometimes anti-metal).

Note that on-metal tags will also work on non-metal surfaces. However, on-metal tag scan distances always tend to be slightly less than standard NFC tags so unless you need tags that will or might go on metal, you are usually better choosing a standard tag.

Pricing

Seritag Product Code : ST749
Current Stock : 2,504 (need more?)We can typically supply additional stock of this product within 2 weeks. However, we very strongly advise you to contact us for exact production schedules for non-stock items before ordering.

Price per tag :
5 - 99$0.60
100 - 999$0.58
1,000 - 9,999$0.56
10,000 - 19,999$0.55
20,000 +Contact Us
(price excludes VAT)Show prices with VAT
(You can encode the tags yourself)
Total Cost :
$-

(excludes VAT)



Product Data

NFC Chip NTAG213
Interface Specification ISO 14443A / 13.56 MHz
Total Memory 144 Bytes
Data Retention 10 years (estimated)
Metal Surfaces (?)Yes
Unique Print (?)Not Available
Real ScanStrength (?)31mm - 40mm
On-Metal ScanStrength (?)16mm - 20mm
Delivery Format Single Units
Weather Resistance Medium
Water Rating Waterproof
Thickness 1 mm
Adhesive Yes, 3M9080 Permanent
Construction Material PVC
Disc Size 30mm Circular
Face Material PVC
Operating Temperature -15C to +60C
Availability Stock Item - Immediate Dispatch
