  3. 45x30mm Tamper Tag NTAG424

45x30mm Tamper Tag NTAG424

  • Will destruct when tried to be removed
  • NTAG424 authentication chip
  • Thin construction - can be used under labels
This is a 45mm x 30mm white NTAG424 scratch tamper-proof label. The face material and structure of this tag is manufactured in a way that once applied, it will break apart when an attempt to remove is made. At which point, the antenna will be damaged and the tag will no longer scan.

This tag is particularly delicate to handle and care must be taken removing from the liner and applying.

Supplied in strips in lower quantities or on a reel in higher numbers.

Note that the NTAG424 is an advanced chip that requires specialised software for encoding and verifying the anti-counterfeit features. Usual NFC mobile apps cannot encode these chips to work with authentication. Ixkio tag management users can use the ixkio mobile app to encode for both redirect or API with full authentication.

We can provide high-speed encoding services for these tags for ixkio users and in some cases other verification systems.

This product is available as special order with unique ID print for visual identification if required. Please contact us for information and ordering.

Using NFC Tamper Labels

There are two main categories of NFC tamper labels - Destruct type (which stop working on tamper) and Detect type (which continue to work but can tell if a tamper has been made). Destruct labels have two sub-types : scratch and peel. Detect have two sub-types : break and capacitive.

Tamper tags don't like movement. They work best on firm, solid and non-flexible surfaces such as glass or rigid plastics.

Scratch Tamper

Scratch tamper tags are designed to disintegrate on an attempt to remove. The tags must be attached to a smooth, clean surface. If you are testing, give the label plenty of time (ideally 24 hours) for the adhesive to get a good grip. An attempt to remove will chip away at the tag and destroy the antenna. These tags can be placed behind other labels.

Peel Tamper

Peel tamper tags have two layers which are designed to separate when an attempt is made to remove. The tags must be applied to a smooth, clean surface. As with scratch tags, give plenty of time for the adhesive to reach full strength before testing removal. On removal, the top layer will separate from the base layer destroying the antenna and preventing the tag working.

Authentication Tags Explained

A quick guide

A normal NFC chip, such as the NTAG213, NTAG215 or iCODE SLIX can store a URL (web link) in it's memory. When scanned, it presents this link to the scanner (a mobile phone for example). It presents the same link every time, in a similar way to a QR Code.

An authentication NFC chip, such as the NTAG424, works differently. When the URL is encoded onto the tag, a secret key is also encoded, along with some other settings. When the tag is scanned, it presents the URL but also a unique code which is generated using this secret key. This unique code changes on every scan and can be verified using an authentication server which will hold the same secret key.

Note that the full name for the NTAG424 chip is the NTAG424 DNA. We usually just refer to it as the NTAG424 chip.

Using authentication chips

As this code is unique for each scan, these NTAG424 NFC tags can be used for anti-counterfeit and authentication. It makes them extremely powerful as they can be used to ensure that the tag is the exact tag that you expect it to be. All from a simple scan with a mobile phone (no special app required).

Authentication chips have a huge range of use cases from the obvious protection of luxury goods, artwork and pharmacuiticals to supply chain security, document authentication, ticketing, proof of physical presence, secure log-on and more.

Encoding authentication chips

While standard NFC tags can be easily encoded with any of the free mobile phone applications, encoding NTAG424 chips is substantially more complicated. You have four choices :

  1. Use NXP's TagXplorer desktop software to encode the tags (note that NXP no longer support this software but at the time of writing it was still available to download)
  2. Build your own encoding system.
  3. Get Seritag to encode your tags for you
  4. Use our Ixkio Tag Management platform and encode with our ixkio mobile app.

More information

For more information on buying and using NTAG424 or other authentication chips, contact us or read more about NFC tag authentication.



Ixkio NFC Tag Management

What is tag management ?

NFC tag management allows you to dynamically control the destination URL of your NFC tags. It provides tracking and stats, authentication services for anti-counterfiet tags, and a host of features to assist in getting the right tags in the right locations or products. Ixkio even allows you to encode your own NTAG213, iCODE or NTAG424 tags with our mobile App.

Using ixkio

Ixkio is designed as an engine for your NFC tags and works alongside your existing ecommerce or marketing website. You don't need to spend time and money to recreate your branding or content. Ixkio can be used as an API system for authentication or more commonly a redirect system - managing dynamic links. Of course, you can attach your own domain so the tags are encoded with your brand.

Tags can be encoded by us at supply (free of charge for labels) or you can encode your own tags - including NTAG424 - usng our mobile app or your own mehtods. You can then manage and alter the tag destination using rules and dynamic data features to display pages from your exiting website.

Ixkio provides additional powerful tools to protect your landing page when using authentication tags and can even pass tag related information from ixkio - such as serial numbers or prodict information - to be dynamically displayed on your page. We have even built a Shopify App to make integration easier for Shopify users.

Can ixkio be used for Digital Product Passports (DPP) ?

Absolutely. Ixkio has a comprehensuve data factilities engineered to allow extensive product information to be connected to your tags. This data can then be dynamcially passed to your existing website for display if required.

Getting started

Ixkio subscriptions can be purchased online at ixkio.com or contact us for more information.

Pricing

Seritag Product Code : ST948
Current Stock : 206 (need more?)We can typically supply additional stock of this product within 4 weeks. However, we very strongly advise you to contact us for exact production schedules for non-stock items before ordering.

Price per tag :
10 - 99$1.77
100 - 199$1.63
200 - 499$1.49
500 - 999$1.38
1,000 - 1,999$1.24
2,000 - 4,999$1.20
5,000 +Contact Us
(price excludes VAT)Show prices with VAT
(You can encode the tags yourself)
Total Cost :
$-

(excludes VAT)



Product Data

NFC Chip NTAG424
Interface Specification ISO 14443 / 13.56 MHz / NFC Forum Type 4
Total Memory 416 Bytes (User)
Data Retention 50 years (estimated)
Metal Surfaces (?)Not suitable
Unique Print (?)Not Available
NFC Label Format Tamper
Label Size 45x30mm Rectangle
Adhesive Yes, Permanent
Delivery Format Reel / Strips of 5
