Special Order Product

Factory Tag

  • 2 screw holes for easy and secure attachment to assets
  • Large plate face for visual identification
  • Sturdy plastic to withstand harsh environments
A very heavy duty, durable and waterproof industrial use NTAG213 NFC disc tag. For the harshest environments, this tag can be used on both metal and non-metal surfaces. Optional 3M adhesive backing.

8mm thick, 50mm diameter with two 4.5mm screw holes Manufactured in industrial nylon and IP68 rated. The tag can withstand operating temperatures from -40C to +85C.

The flat plate area can be laser etched with an ID and/or QR code as required.

This is a special order product and only available made to order. Production times for this specialist product can be 8-10 weeks.

Also consider the more economical ABS Bar Tag

On-Metal Tags Explained

Normal NFC tags do not work when placed directly onto metal surfaces. Therefore, when using NFC tags on metal you either need a gap of at least 0.5 cm between the tag and the metal or you can use a special tag which has a barrier material, called ferrite, between the NFC tag and the adhesive. This barrier material gives you the same effect as if you had created the gap between the metal surface and the tag.

These NFC tags designed so they can be placed on metal surfaces are called 'on-metal' tags (or sometimes anti-metal).

Note that on-metal tags will also work on non-metal surfaces. However, on-metal tag scan distances always tend to be slightly less than standard NFC tags so unless you need tags that will or might go on metal, you are usually better choosing a standard tag.

This is a Special Order product which we will manufacture specifically for you. Current production time is estimated at 8 weeks.

Pricing

Seritag Product Code : ST905

Price per tag :
500 - 999$3.33
1,000 - 1,999$3.14
2,000 - 2,499$2.98
2,500 - 4,999$2.62
5,000 - 9,999$2.53
10,000 - 19,999$2.45
20,000 +Contact Us
(price excludes VAT)Show prices with VAT
(You can encode the tags yourself)
Total Cost :
$-

(excludes VAT)



Product Data

NFC Chip NTAG213
Interface Specification ISO 14443A / 13.56 MHz
Total Memory 144 Bytes
Data Retention 10 years (estimated)
Metal Surfaces (?)Yes
Unique Print (?)ID & QR Print Available
Delivery Format Single Units
Disc Size 50mm Circular
Thickness 8.2mm
Hole Size 4.5 mm
Availability Special Order
Real ScanStrength (?)41mm - 50mm
On-Metal ScanStrength (?)
Adhesive Optional
Weather Resistance Very High
IP Rating IP68
Construction Material PA6 Industrial Nylon
Printing Option Laser etched ID
Operating Temperature -40C to +85C
Water Rating Waterproof
